Manufacturer & Exporter of Single Phase Flange Motor. Our product range also comprises of Three Phase Electrical Motors, Industrial Motors and Submersible Pumps.
Flange Mounted Single Phase Motor
Single Phase Flange Motor
Product Details :
| Power | < 10 KW |
| Brand | INDOTECH |
| Phase | 1 |
| Speed | < 2000 RPM |
| Voltage | 230 |
| Mounting Type | Flange |
| Ambient Temperature | 60 |
| No Of Poles | 4 |
Specifications :
| Model | Power | Voltage(V) | Current(A) | Speed(r.p.m) | Eff(%) | Power factor | Locked rotor torque Rated torque | Locked rotor current rated current | Start current (A) | |
| KW | ||||||||||
| MY631-2 | 0.18 | 1/4 | 220 | 1.48 | 2800 | 60 | 0.92 | 0.4 | 1.7 | 5 |
| MY632-2 | 0.25 | 1/3 | 220 | 1.96 | 2800 | 63 | 0.92 | 0.4 | 1.7 | 7 |
| MY711-2 | 0.37 | 1/2 | 220 | 2.73 | 2800 | 67 | 0.92 | 0.35 | 1.7 | 10 |
| MY712-2 | 0.55 | 3/4 | 220 | 3.88 | 2800 | 70 | 0.92 | 0.35 | 1.7 | 15 |
| MY801-2 | 0.75 | 1 | 220 | 5.15 | 2800 | 72 | 0.92 | 0.33 | 1.7 | 20 |
Abiding by ethical business practices, we are capable of bringing best quality Single Phase Flange Motor forth for our revered clients. Made available with flange and face mounting construction, it is widely praised in the market. Owing to its sturdy construction and excellent performance, the offered range of single phase flange motors offered by us has been a preferred choice of our clients.
